Lemon ET Bronze 80Plus ATX computer power supply non-modular
    • 1/1

Lemon ET Bronze 80Plus ATX computer power supply non-modular

share
WeChat
copy Link
Facebook
X
LinkedIn
Pinterest
Whatsapp
Line
Tumblr
Series Xuanwu
Model B1000X
Safety &EMI/EMC 3C &CE &CB
Efficiency 80 PLUS Bronze Certified
Intel PSDG ATX 12V V2.52 version
Capacitor 100% Chinese
Working temperature (℃) 0 to 50
Operating altitude 5000 above sea level
Storage temperature (℃) -40 to 70
MTBF(full load@25℃ ambient) >100,000 hours
Application Personal Desktop computer
Wattage:
550W
750W
Casing selection
Black case
DIY relief carving
Modular
Fully Modular
Semi modular
Non Modular
AC input
100-240V, 50-60HZ
200-240V,50-60HZ
Color
Black
White
Contact Us!
Add to inquiry
Detail
AC INPUTInput Voltage: 100 - 240V~
Input Current: 10A Max.
Frequency: 47Hz-63Hz
DC OUTPUT
+3.3V+5V+12V-12V-5VSB
Max Output Current18A18A83.3A0.3A3A
Max Output Power100W
999.6W3.6W15W
Total Power1000W


20+4pins 550mm


CPU (4+4pins) 700+150mm*2


L+L+L+L 450+150+150+150mm


SATA+SATA+SATA+SATA 450+150+150+150mm*2


PCIe (6+2pins) 600+150mm*3


12V-2x6 (12+4 Pins to 12+4 Pins) 600mm

12V-2x6 (12+4 Pins to 12+4 Pins).png
